WOOD LATHE MACHINE NESTO 5 AXIS ULTRA
Brand: Nesto
The machine uses high-resolution Panasonic servo motors, made in Japan. The rotating part axis features a "Direct Drive" function and can operate with a 5 kW servo motor at a speed of 4500 rpm. All axes use precision ball screws and nuts. The workpiece length setting can be adjusted with a single knob, ensuring time savings and maintaining the linearity of the support. The control unit features remote control functionality and provides the user with convenience through features such as task sequencing, detailed reports, and 3D display of the workpiece status.
Technical features and options
- Workpiece dimensions: Maximum diameter: 400 mm – Maximum length 1200 mm,
- Machine dimensions: Length: 3950 mm, Width: 3720 mm, Height: 3900 mm
- Control unit: TPA control unit (Italian)
- Z-axis movement: 1200 mm
- X-axis movement: 225 mm
- Long axis speed (Z): 70 m/min
- Short axis speed (X): 30 m/min
- Vertical axis speed (Y): 20 m/min
- 5th axis (A): +90/-90 degrees
- Lathe speed: 3000 rpm (direct drive)
- Installed power: 33 kW
- Weight: 4600 kg
- Lubrication unit: Automatic lubrication ILC
- Workpiece clamping: Pneumatic piston (7 bar)
- Workpiece length adjustment: Easy adjustment via remote control (no tools, no screws)
- Cutting blade: Triangular blade made of special steel
- Rounded blades: Rounded blade made of special steel, cutting tool for machining
- Tool magazine: 5-position
- Spindle: HiTECO 8.5 kW, 24,000 rpm
- Drawing program: Italian CAD-CAM program Pegasus 5 Axis Cad&Cam Program
