EDGE BANDER CASADEI 450 PM

Categories: ,

Brand: Casadei

Automatic edge bander with inferior holt- melt glue pot (EVA), chain panel – feeding and pre-milling.

Technical features and options

  • Feed speed (m/min): 7
  • Material thickness (mm): 8-45
  • Edge thickness: – edging without automatic feeder (mm): 0.4-3
  • Max. disc diameter with edging (mm): 800
  • Distance between workpieces (mm): 600
  • Min. material length (side being processed) (mm): 210
  • Min. material width (mm): 95
  • Max. lateral support extension with rollers (mm): 430
  • Compressed air pressure (bar): 6.5
  • Compressed air consumption (NL/min): 300
  • Dust extraction outlet diameters (mm): 1xfi120 + 2xfi80
  • Min. air speed for dust extraction (m/sec): 20
  • Min. efficiency of the dust extraction unit (m³/min): 820

Logical functions controlled by PLC:

  • Thermostatic control of adhesive with automatic standby mode and temperature indicator
  • LED backlit buttons for selecting operational units
  • Complete automation control of various working units with an encoder located on the panel feeding system
  • Diagnostic system with messages for machine operation and maintenance
  • Statistical operational data: total machine usage time, total and partial edge material usage meter
