CUTTING TABLE BIESSE GENIUS RS-A
CUTTING TABLE BIESSE GENIUS RS-A
CUTTING TABLE BIESSE GENIUS RS-A
CUTTING TABLE BIESSE GENIUS RS-A

CUTTING TABLE BIESSE GENIUS RS-A

ID: 2544

Categories: ,

Brand: Biesse

Stock status: in stock

An extremely compact, all-inclusive cutting table, engineered to process a wide range of glass types effortlessly, delivering a complete solution in a single machine.

Log in to view pricing

Technical features and options

  • Working dimensions: 3710 × 2600 mm
  • Axis speed: 200 m/min
  • Tilting arms for glass loading with a load capacity of 300 kg
  • 3 breaking beams (2 transverse + 1 longitudinal)
  • Cutting range: 3 – 19 mm
  • Total installed power: 8 kW
  • Working table height: 900 mm (adjustable range: -15, +40 mm) Options includedPCC4050255 1

    Monolithic tool kit made by:

    1 Wheel-holder spindle for metal clip

    1 Spindle with spring for plastic cutting, inclusive of plastic cutting clip

    1 Wheel-holder spindle for 3-8-2 wheels for large thicknesses

    1 Metal clip + wheel – D. 5.6 x 145°

    1 Metal clip + wheel – D. 5.6 x 150°

    1 Metal clip + wheel – D. 5.6 x 155°

    1 Metal clip + wheel – D. 5.6 x 160°

    1 3-8-2 wheel for large thicknesses – 160°

    PCC2006025 1

    Perfect Cut ONE: for machine PC with ability mono machine (float or laminated); software straight and shaped optimization. Includes label creating and printing software (printer not included). Import of work order lists into the optimizer using text or excel type files included. Perfect Cad included. Two (2) years of service assistance and updating included.

See how it works
