VERTICAL WASHER NEPTUN LV EVO
Brand: Neptun
LV Evo falls into the medium category of the Neptun series of vertical washing machines, placing itself between the top of the range Wave and Superinox and the cheaper LV Top.
Technical features and options
Thanks to the powerful PLC, It can be set up with several options such as Ecosave system for reduction of energy consumption, flow meters, antistatic bar, water quality control and many more functions for special applications. The LV Evo, with its sturdy stainless steel supporting structure, is the most automated mid-level vertical washing machine on the market and can easily be defined as the best synthesis of budget, performance and automation.
Supporting structure in stainless:
- Supporting structure in stainless steel with tempered glass doors, with independent frames for the washing and drying sections. Motorization of front and rear brushes mounted on the structure for better protection from water and humidity.
Powerful touch screen control:
- Powerful touch screen control unit for machine functionality management, remote diagnosis, scheduled maintenance and numerous innovative optional functions similar to the superior Wave and Superinox models.
Configurable:
- Available with 4 or 6 brushes and prewashing. Tank in stainless steel. Separated water circuits with pumps. Resistance for water heating with safety floater.
Glass conveying system:
- Glass conveying system with rubber scratchproof rollers, driven by maintenance free conical gears. Mechanical transmission in stainless steel. Axes of the conveying rollers and of the brushes made in stainless steel.
Automatism:
- Automatic opening of the machine by means of a glass thickness reading sensor. The glass thickness can also be acquired by the machine in upstream line (straight-line edgers or vertical work center) or downstream.
Optional:
- Special Brushes – Soft or high density brushes according to the processing needs
- Heating – Heating device for a tank up to 60°
- Ecosave Base – Patented system for energy saving according to the size of the glass. Allows a reduction in noise and electricity consumption by up to 60%
- CN centers connection kit – Connection to vertical numerical control centers
- Quickservice – It allows Neptun full access for assistance and updates, not only to the operator panel but also to PLCs, drivers, motors and sensors.
- Flow switches – Flow switches to check the filter cleaning status
