WRAPPING MACHINE HORBITEK HORIZON 800

• Wrapping width min. 80 max. 700 mm, wrapping length min. 400 max. 3000 mm
• Wrapping height min. 10 max. 300mm, weight max. 100 kg
• Working level mm 1000
• Conveyor speed m/min 10-15
• Max capacity Packs/h (*) 100
• Compressed air demand Bar (+/-1) 6; 30NI/min
• Power supply 220V 1P + N + T (3 phases) 2 kW
• The color of the permanent components is Ral 7040 The color of the moving components is Ral 6037
  (*) – the value given is based on a stable load of 2000 mm and 20 wraps of film (therefore, the capacity is variable as a function of the length of the load and the wrapping cycle).

Film Specifications:

• Material 100% LLDPE
• Thickness 15 – 27 Micron
• Roll weight max 9 kg
• Tape – width 125 mm
• Internal diameter 76 mm
• The outer diameter of the roll max 250 mm

Semi-automatic wrapping machine with a horizontal axis and an encircling ring with an inner diameter of 800 mm. Welded steel construction, Construction complete with access door to replace the roller with electromechanical micro protection. The ring is equipped with a high-quality steel wheel that can withstand up to 120 rpm.
The rotation is performed by a self-locking motor driven by an inverter. The film application trolley, supporting the film roll, provides adjustable tension depending on production needs. Input/output pinch rollers provide increased rigidity to the load during the wrapping cycle.
Each group consists of two PVC-coated idle rollers attached to the support. Activation of the unit by means of a pneumatic actuator, the possibility of adjusting the pressure by means of a manometer. Electrical panel built into the machine, control by PLC.

Conveyors:

• Conveyors Loading conveyor belt L 900 x 700 mm controlled by an inverter.
• Unloading conveyor belt L 900 x 700 mm controlled by an inverter.
