VACUUM MANIPULATOR ELEPHANT B250/5 + KQ3SD/1S + TV2
Brand: Elephant
Crane with vacuum gripper dedicated for wooden elements and decking.
Technical features and options
Crane column model B-250/5
- Load capacity: 250 kg
- Boom reach: 5 m
- Column height: 3.5 m
- Height under the boom: 2.8 m
- Hook height: 2.3 m
- Manual trolley included
- Rotation angle: 270°
Electric hoist, manually moved, model KQ3SD/1S
- Load capacity: 250 kg
- Lifting speed* 10/1.7 m/min
- Power supply – control panel: 24 V
- Power supply: 380 V, 50 Hz
- Hook displacement: 3 m
- Hoist power: 0.5 kW
Vacuum lift for wooden elements and boards model TV2
- Load capacity 200 kg
- 2 suction cups 700×160 mm
