CNC MACHINE COMEC MD JAMB 11X

CNC MACHINE COMEC MD JAMB 11X

Categories: ,

Brand: Comec

MD JAMB 11X is the ideal solution for cutting, milling or drilling operations on all faces of long elements

Technical features and options

Left / Central / Right Working Heads independently controlled numerically
Side Heads 1+1 cutting/drilling work units

  • Right And Left Side Heads:
  1. 1+1 spindles, 4 kW for cutting/milling with double outlets
  2. 1+1 spindles, 7 kW for drilling/milling

Central Head

  • Working movement:
  1. X-axis: 2700 mm
  2. Y-axis: 220 mm
  3. Z-axis: 135 mm
  • Vertical Drilling Units:
  1. Vertical milling spindle, 5.6 kW
  2. Vertical spindle with a special drilling head, 1.5 kW
  3. 1 drilling head with 2 horizontal drills with a 22 mm spacing and one drill (anuba)
  • Horizontal Work Units:
  1. 2 Milling spindles, 3.3 kW each, with separate inverters
  2. Oscillating spindle, 1.8 kW, equipped with an inverter
  3. Special Loading Tables for fully assembled door frames. Full automation of the regulation
  4. The table for securing elements is divided into 4 parts, adjustable on guides
  5. Automatic Loading and Unloading System
  6. Waste conveyor belt placed beneath the working area
  7. Protective Cabin
  8. Control Cabinet with industrial computer
