Technical features and options
- Max cutting length with the scoring saw: 2800 mm
- Max cutting width on the parallel guide: 1300 mm
- Saw blade tilt range: 0º – 45º
- Max cutting height with a Ø 300 mm saw blade: 100 mm
- Max cutting height with the saw blade at a 45º angle (Ø 300 mm): 68 mm
- Max saw blade diameter and arbor size: 300 / 30 mm
- Max undercutter diameter / arbor size: 120 / 20 mm
- Saw blade rotational speed: 4000 rpm
- Undercutter rotational speed: 8000 rpm
- Upper/lower dust extraction outlet: Ø 100 mm
- Main motor power: 4 kW 50 Hz
- Scoring saw motor power: 0.55 kW
- Noise level according to EN 27960 standard: 81.2 – 83.9 dB (A)
- Max extension to the stops: 3200 mm
