Technical features and options
- Useful working width: 530 mm
- Total table length: 3000 mm
- Feed table length: 1800 mm
- Inclined guide (0-45°): 1500 x 175 mm
- Main motor power: 4 kW 50 Hz
- Noise level according to EN27960 standard: 82.8-88.8 dB (A)
- Spindle guard
- Depth of planing readout
- Spiral shaft with 3 spirals, includes:
- Carbide knives (blades) 15x15x2.5 mm R95 37°
- 2 TORX T20 bits
- 1 torque wrench calibrated to 5.7 Nm
- Depth of planing readout
- Manual control of feed table movement
- Maximum material removal thickness: 8 mm
- Electrical installation in compliance with CE Standards
- Dust extraction port Ø 150
- Machine weight: 700 kg
