Technical features and options
- Min/Max working height: 3 mm / 310 mm
- Maximum planing thickness: 8 mm
- Spindle diameter: Ø120 mm
- Number of knives: 4 pcs
- Spindle speed: 4,800 RPM
- Table lift mechanism using 4 trapezoidal screws
- Automatic table lifting with micro metric adjustment
- Height reading accuracy with decimal precision
- Dust extraction port: Ø150 mm
- Electromagnetic brake
- Machine weight: 740 kg
- Feed speed (step adjustment): 5-7.5-11.5-18 m/min
- Minimum length of planed element: 250 mm
- Main motor power: 5.5 kW (7.5 HP) 50 Hz
- Noise level according to EN27960 standard: 86-90 dB (A)
