Technical features and options
- Spindle Motor Power (1st Unit – Planer Spindle): 4 kW (5.5 HP)
- Right Spindle Motor Power (2nd Unit – Milling Spindle): 4 kW (5.5 HP)
- Left Spindle Motor Power (3rd Unit – Milling Spindle): 4 kW (5.5 HP)
- Upper Horizontal Spindle Motor Power (4th Unit): 4 kW (5.5 HP)
- Feed Motor Power: 0.75 kW (1 HP)
- Lifting and Lowering Motor Power: 0.37 kW (0.5 HP)
- Max. Working Width (with ø 80 mm tool): 130 mm
- Min. Working Width (with ø 80 mm tool): 25 mm
- Max. Working Height (with ø 80 mm tool): 130 mm
- Min. Working Height (with ø 80 mm tool): 8 mm
- Min. Length of Single Workpiece: 250 mm
- Spindle Rotational Speed: 6000 RPM
- Drive Roller Diameter (toothed and rubberized): 130 mm
- Spindle Tool Holder Diameter: 35 mm
- Planing Tool Dimensions for Horizontal Spindles: 80 mm x 140 mm
- Planing Tool Dimensions for Vertical Spindles: 80 mm x 140 mm
- Dust Extraction Port Diameter (6 pcs.): 120 mm
- Voltage: V380/400-HZ50-3PH+N
