DRILLING MACHINE FOR NARROW PANELS NANXING WDA0424L-22
Brand: Nanxing
It is specifically designed for the precise boring of small, narrow boards such as drawer panels, bed baffles, cabinets, and other compact furniture components.
Technical features and options
With an automatic feeding system, it offers two processing methods: a return-feed system that simplifies the boring process, allowing completion in a single operation, and a through-feed option for larger panels.
An independent board-feeding storage system ensures surface protection, while an intuitive system enables easy monitoring of board counting, positioning, storage, and boring at a glance, streamlining the entire operation.
- Panel length: 230-2200mm,
- Feeding mode: Pneumatic,
- Panel width: 30-400mm,
- Total power: 20kW,
- Panel thickness: 10-25 mm,
- Working speed: 12-18 pcs/min,
- Spacing of drills: 32 mm,
- Machine size: 3700*2320*1970 mm,
- Drilling motor power: 1.5 kW * 10,
- Machine weight: 3200 kg.
