AUTOMATIC PAINTING MACHINE CEFLA MITO P
Brand: Cefla
Spraying machine MITO P with one arm, dry air filtration and paper covered conveyor belt. The workpieces are placed on a paper-covered belt which is unrolled each time it is loaded in order to always ensure a perfect surface cleanliness. Adhesion of the paper is achieved by a vacuum system. Stretching of the paper is carried out by means of an electronic alignment system. The central axis holds one arm with a quick-change spray gun holder (preparation for max. 4 guns), manual height adjustment. 2 circuits with recirculation and paint filters. Equipment in stainless steel.
Technical features and options
The spray automat is designed for coating flat and profiled panels with water-based and solvent-based paints.
- Max. working width: 1300 mm
- Max. working thickness: 60 mm
- Min. element length: 300 mm
- Working speed: 2-4 m/min
- Touchscreen control panel
The air supply system, the patented PLENUM, provides:
- Paint savings
- Better application quality
- Improved cleanliness within the machine
