Brand: Sarmax

Brushing of the wood is a good way to customise the product and to provide an additional, innovative and different service to customers. The operation involves modifying the surfaces, highlighting the grain of the wood, giving a natural sophisticated and unique appearance to the product. Combining the brushing parameters such as depth and softness and with the use of different types of brushes it is possible to turn an everyday wooden item into something unique and unrepeatable.

Technical features and options

  • Max. working width: 600 mm
  • Max. working thickness: 300 mm
  • Min. element length: 300 mm
  • Fixed operating level
  • Feed table with inverter: 3 – 15 m/min.
  • Machine dimensions: 1300 x 1300 x 1600 mm
  • Machine weight: 600 kg

FIRST WORKING UNIT

  • Structuring roller with a metal brush
  • Brush diameter: 200 mm
  • Motor: 4 kW with inverter
  • Speed: 400-1300 rpm
  • Rotation inversion

SECOND WORKING UNIT

  • Structuring roller with Tynex brush
  • Brush diameter: 200 mm
  • Motor: 4 kW with inverter
  • Speed: 400-1300 rpm
  • Rotation inversion
