CUTTING TABLE BIESSE GENIUS CT-A
CUTTING TABLE BIESSE GENIUS CT-A - Image 2
CUTTING TABLE BIESSE GENIUS CT-A - Image 3
CUTTING TABLE BIESSE GENIUS CT-A - Image 4

CUTTING TABLE BIESSE GENIUS CT-A

Categories: ,

Brand: Biesse

A numerically controlled table with three-axis control, designed for straight-line and profiled cutting of monolithic and special glass surfaces.

Technical features and options

This table features a low-friction felt surface with an air cushion created by a high-efficiency, low-noise fan, enabling easy glass movement. Mechanical limiters with a loading and unloading function for double sheets are included, and it can work with low-emission glass.

GENIUS 37 CT-A TECHNICAL DATA:

  • Work surface dimensions: 3710×2750 mm (3810×2750 optional)
  • Glass thickness: 2-19 mm
  • Cutting head positioning accuracy: +/- 0.15 mm
  • Max. cutting speed: 200 m/min
  • Total weight: 2400 kg

GENIUS 61 CT-A TECHNICAL DATA:

  • Work surface dimensions: 6100×3350 mm
  • Glass thickness: 2-19 mm
  • Cutting head positioning accuracy: +/- 0.15 mm
  • Max. cutting speed: 200 m/min
  • Total weight: 3800 kg
